Product Details:
Payment & Shipping Terms:
|
Materials: | Fiberglass +Korea PVC | Overall Length: | 20 Feet |
---|---|---|---|
Net Weight: | 590KGS | Power: | 150HP |
Max Load: | 1587KGS | Beam: | 256cm |
Max Person: | 12 Persons | ||
High Light: | Rigid Inflatable Boat,Inflatable Motor Boat |
600cm Korea PVC big sunbath bed inflatable rib boat rib600 rigid hull large center console
This boat is with very big sunbath bed for luxury sunbathing !!!
The Patrol is a commercial quality range of RIBs designed and hand built to withstand the toughest conditions.
The hull is built in fiberglass and orca hypalon or PVC tube . With their super deep V, wide chines and large diameter tube, they offer high maneuverability, high safety and a soft dry ride even in the roughest conditions.
The Patrol boats carry large loads and plane quickly and easily with little horsepower.
These boats are ideal pursuit craft or work boat and can be configured with different seating and console options.
When safety, toughness and reliability matter the Patrol range will be your first choice.
A rigid inflatable boat (RIB) is a light boat constructed with a solid, shaped hull and flexible tubes at the gunwale. Featuring stable design, high performance and high capacity, it is a development of the inflatable boat. The inflatable collar allows the vessel to maintain buoyancy even if a large quantity of water is shipped aboard due to bad sea conditions.
RIB can be used as work boats in trades that operate on the water, lifeboats and military craft that are used in patrol roles and to transport troops between vessels or ashore.
The rigid inflatable boat gives you the feeling and performance of a ship. It has proper hardness and deep V-shaped bottom. RIB's fiberglass hull enables it to cleave through the waves like an ordinary rigid boat. However, inflated tubes make RIB more stable and buoyant than ordinary rigid boat. Moreover, RIB's light weight makes it easy to be transported by a trailer.
1. Parameter:
Model | Length(cm) | Beam(cm) | Hull length(cm) | Hull width(cm) | No.of chamber | Tube Dia.(cm) | Max persons | Engine power(HP) | Net weight(kgs) | Packing size(cm) |
RIB600 | 600 | 256 | 560 | 193 | 5 | 54 | 12 | 150 | 590 | 560*190*110 |
2. Standard feature:
center console with cushions(including windshield,4 point switch ,oil gauge),
seat box(with cushions and SS frame roll) , bow box,
steering system,sewage pump,120L Built-in tank ,
100A battery with battery box, bandage , anchor and anchor rope ,
fiberglass archor tray ,fiberglass arch with navigation lights
,stainless steel sunshade,shower facility ,
50L built-in tank , clean water pump , stainless steel ladder, electric air pump etc.
3. Optional :
Teak floor , boat trailer ,fiberglass step , etc.
4. Other Features :
★ Adhesive structure
★ Polyurethane glue
★ Cold weding
★ Made by hand
★ Four layers reinforced seams
Construction:
Polyurethane glue is used to cold glue all our seams
Every boat is made by hand
Four layers of reinforced seams are used to ensure strength
5. Warranty :
We also provide excellent after-sale services and 3 - 5 year (3 years for PVC , 5 years for Hypalon )
warranty of the hull and materials.Each boat comes with a repair kit containing the maintenance tools and materials(fabrid and glue).The replacement parts will be offered for free within warranty period.In the event that the boat has really quality defects within warranty period,we will offer free replacement parts after the receipt of the related pictures and descriptions supporting the factor; In case of serious quality problems ,a replacement boat will be sent to the customers with next order shipment.
