Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments

China Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments supplier
Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments supplier Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments supplier Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments supplier Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments supplier

Large Image :  Deep - V Fiberglass Bottom Inflatable Boat 19 Ft With Customized Equipments

Product Details:

Place of Origin: Shandong , China
Brand Name: CMEC
Certification: CE
Model Number: Rib580B

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Carton and weaving bag
Delivery Time: 10 -15 days for sample
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 PCS per Month
Contact Now
Detailed Product Description
Materials: Fiberglass Hull +Orca Hypalon Tube Beam: 260cm
Hull Length: 500cm Power: 90-115HP
Net Weight: 520KGS Max Person: 9-10 Persons

19 feet orca hyalon full colorfull hull big back space inflatable rib boat rib580B with double engines plate



This is the cost-effective boat with pretty and confortable design , it can be with double engines !!!  Large rear cabin space !!!



Rgid inflatable boat/RIB boat 5.8, 9-10 persons PVC or hypalon



1. Deep-V fiberglass bottom makes it stable and strong.

2. Fiberglass hull and tube are same color to looks nice and harmony

3.120L big capacity built-in fuel tank for enough supply

4. PVC net clamping cloth makes it resistant and intensive.

5. Double engien to guarantee the sustaining sailing on the sea

6. Capacious deck and  boat back to give you more free posture

7. Customized equipments to bring you the willing choice





1. Specification





Model Length(cm) Beam(cm) Hull length(cm) Hull width(cm) No.of chamber Tube Dia.(cm) Max persons Engine power(HP) Net weight(kgs) Packing size(cm)
RIB580B 580 260 500 200 5 54 9-10 90-115 520 520*210*110



2. Standard fittings  :



center console with cushions(including windshield,4 point switch ,oil gauge),

seat box(with cushions and SS frame roll) , bow box,steering system,

sewage pump,120L Built-in tank ,60A battery with battery box,

Life jackets,bandage , anchor and anchor rope ,

fiberglass archor tray ,fiberglass arch  or SS light arch with navigation lights

 back rest with skiing loop ,etc.



3. Optional Equipments :



 boat trailer ,fiberglass step ,bimini Top   etc.



4.  Other Features :







Hypalon features :

Heavy duty 2000 denier polyester reinforced pvc.thickness:

1.2mm.These boats are made with an extremely rugged

material that is very difficult to puncture or tear.our fabric is made with the STS(SOL Type System)process.this does not merely coat the internal reinforcement fabric with an outer

layer,but forces the outer material into the thousands of

tiny gaps in the base fabric weave to form a single

homogenous material.



5. Warranty :



We also provide excellent after-sale services and 3 - 5 year (3 years for PVC , 5 years for Hypalon )

warranty of the hull and materials.Each boat comes with a repair kit containing the maintenance tools and materials(fabrid and glue).The replacement parts will be offered for free within warranty period.In the event that the boat has really quality defects within warranty period,we will offer free replacement parts after the receipt of the related pictures and descriptions supporting the factor; In case of serious quality problems ,a replacement boat will be sent to the customers with next order shipment.
